Connectivity
| Audio output |
3.5 mm jack |
| Video input |
HDMI 2.0 (x 2) |
|
USB 2.0 (x 2) |
|
DVI-I (x 1) |
|
USB 3.0 (x1) |
| Other connections |
micro SD |
| External control |
RJ45 |
|
RS232C (in/out) 2.5 mm jack |
|
IR (in/out) 3.5 mm jack |
| Audio input |
3.5 mm jack |
Convenience
| Remote control signal |
Lockable |
| Placement |
Landscape (18/7) |
|
Portrait (18/7) |
| Energy-saving functions |
Smart Power |
| Network controllable |
RS232 |
|
RJ45 |
| Tiled Matrix |
Up to 3 x 3 |
| Keyboard control |
Lockable |
|
Hidden |
| Signal loop through |
RS232 |
|
IR Loop through |
Accessories
| Included Accessories |
IR sensor cable (1.8 m) (x 1) |
|
RS232 daisy-chain cable |
|
Philips logo (x 1) |
|
AC Power Cord |
|
AC Switch Cover |
|
Quick start guide |
|
Remote control and AAA batteries |
|
RS232 cable |
|
USB cover and screws |
|
Wire Clamper (x 3) |
Internal Player
| Memory |
16 GB |
|
3 GB DDR |
| CPU |
Quad-Core Cortex A55 |
| GPU |
G52 MC1 |
Dimensions
| Set Height |
712.6 mm |
| Wall Mount |
400 mm x 400 mm, M6 |
| Set Width |
1241.8 mm |
| Set Depth |
63.6 mm |
| Set Width (inch) |
48.89 inch |
| Product weight |
16.6 kg |
| Product weight (lb) |
36.60 lb |
| Set Height (inch) |
28.06 inch |
| Set Depth (inch) |
2.50 inch |
| Bezel width |
13.9 mm (Even bezel) |
Sound
| Built-in speakers |
2 x 10 W RMS |
Power
| Energy Label Class |
G |
| Power Saving Features |
Smart Power |
| Consumption (Typical) |
111 W |
| Standby power consumption |
<0.5 W |
| Mains power |
100 ~ 240 VAC |
Multimedia Applications
| USB Playback Video |
MPEG |
|
H.264 |
|
H.263 |
|
H.265 |
|
AVI |
|
MP4 |
|
VP8 |
| USB Playback Picture |
JPEG |
|
BMP |
|
PNG |
| USB Playback Audio |
AAC |
|
HEAAC |
|
MPEG |
Miscellaneous
| On-Screen Display Languages |
English |
|
French |
|
German |
|
Italian |
|
Polish |
|
Turkish |
|
Russian |
|
Simplified Chinese |
|
Spanish |
|
Traditional Chinese |
|
Arabic |
|
Japanese |
| Regulatory approvals |
CE |
|
CB |
|
FCC, Class A |
|
VCCI |
|
RoHS |
|
UL |
| Warranty |
3 year warranty |
Operating conditions
| Temperature range (storage) |
-20 ~ 60 °C |
| Temperature range (operation) |
0 ~ 40 °C |
| Altitude |
0 ~ 3000 m |
| Humidity range (operation)[RH] |
20~80% RH (No condensation) |
| Humidity range (storage) [RH] |
5~95% RH (No condensation) |
| MTBF |
50,000 hour(s) |
Picture/Display
| Panel resolution |
3840 x 2160 |
| Diagonal screen size (metric) |
138.7 cm |
| Brightness |
400 cd/m² |
| Pixel pitch |
0.315 x 0.315 mm |
| Optimum resolution |
3840 x 2160 @ 60 Hz |
| Picture enhancement |
3/2 - 2/2 motion pull down |
|
Dynamic contrast enhancement |
|
Progressive scan |
| Display colours |
1.07 Billion |
| Viewing angle (horizontal) |
178 degree |
| Dynamic contrast ratio |
500,000:1 |
| Aspect ratio |
16:9 |
| Panel technology |
ADS |
| Operating system |
Android 10 |
| Response time (typical) |
9 ms |
| Haze |
2% |
| Diagonal screen size (inch) |
54.6 inch |
| Viewing angle (vertical) |
178 degree |
| Contrast ratio (typical) |
1300:1 |
Supported Display Resolution
| Video formats |
1080p, 50, 60 Hz |
|
1080i, 50, 60 Hz |
|
720p, 50,60 Hz |
|
2160p, 50, 60 Hz |
| Computer formats |
1920 x 1080, 60 Hz |
|
1600 x 1200, 60 Hz |
|
1440 x 900, 60 Hz |
|
1280 x 1024, 60 Hz |
|
1280 x 720, 60 Hz |
|
1280 x 800, 60 Hz |
|
1024 x 768, 60, 70, 75 Hz |
|
1680 x 1050, 60 Hz |
|
3840 x 2160, 60 Hz |
